DB Electrical SHI0128 Starter Compatible with/Replacement for Mariner Mercury, 75Elhpt 75Elpt 90Elhpt 4-Stroke 2000-2005, 90Elpt 90Exlpt 2000-2005, F100Tlr F100Txr F75Tlr 1999-2002 MOT5017 3430

**Verify the part fits before purchasing**Specs:Unit Type: StarterVoltage: 12Rotation: CCWTeeth: 13KW: 1.4Dimension: Replacement Unit:, Gear OD: 1.571in / 39.9mm, Mtg. Ear Holes: 8.5mm Unthreaded, Notes: Battery Stud M8-1.25 Threaded, 130mm Ignition Lead, 100mm Battery Lead, Starter Type: PMGRBrief: Mercury Outboards 75, 90HP 4-StrokeYamaha Outboards 75, 80, 100HP 4-StrokeReplaces OEM Numbers:API MARINE: MOT5017ARCO MARINE: 3430ARROWHEAD: SHI0128ARROWHEAD (OEM): S114-828DNARROWHEAD (OEM) (OLD): S114-828B, S114-828C, S114-828CNEMP PARTS: 4-6425HITACHI: S114-828B, S114-828CJ & N: 410-44071LESTER: 18347MERCURY MARINE: 50-804312T1, 804312T1QUICKSILVER: 8M6007420SIERRA MARINE: 18-6425WAI: 18347NYAMAHA: 67F-81800-00-00, 67F-81800-01-00, 67F-81800-02-00Compatible With/Replacement For:MARINER 75ELHPT 4-Stroke 2000-2001, 75ELPT 4-Stroke 2000-2001, 90ELHPT 4-Stroke 2000-2001, 90ELPT 4-Stroke 2000-2001, 90ELPT Coastal 4-Stroke 2000-2000, 90EXLPT Saltwater 4-Stroke 2001-2001MERCURY MARINE 75.0HP - SN 0G960500 Thru 0T800999 All, 75.0HP - SN 0T801000 Thru 1B226999 All, 75.0HP Bodensee - SN 0G960500 Thru 0T800999 All, 75.0HP Bodensee - SN 0T801000 Thru 1B226999 All, 75ELHPT 4-Stroke 2000-2001, 75ELPT 4-Stroke 2000-2005, 90.0HP - SN 0G960500 Thru 0T800999 All, 90.0HP - SN 0T801000 Thru 1B226999 All, 90ELHPT 4-Stroke 2000-2001, 90ELPT 4-Stroke 2000-2005, 90ELPT Saltwater 4-Stroke 2004-2005, 90EXLPT Saltwater 4-Stroke 2001-2005YAMAHA F100TLR 1999-1999, F100TLR 2000-2000, F100TLR 2001-2003, F100TXR 1999-1999, F100TXR 2000-2000, F100TXR 2001-2003, F75TLR 2003-2004, F80TJR 2002-2003, F80TLR 2000-2000, F80TLR 2001-2003, F80TXR 1999-1999, F80TXR 2000-2000, F90TJR 2003-2004, F90TLR 2003-2004

• Specs: Starter, Voltage: 12, Rotation: CCW, Teeth: 13, KW: 1.4, Dimension: Replacement Unit:, Gear OD: 1.571in / 39.9mm, Mtg. Ear Holes: 8.5mm Unthreaded, Notes: Battery Stud M8-1.25 Threaded, 130mm Ignition Lead, 100mm Battery Lead, Starter Type: PMGR, Brief: Mercury Outboards 75, 90HP 4-Stroke, Yamaha Outboards 75, 80, 100HP 4-Stroke
• Replaces OEM Numbers: API MARINE: MOT5017, ARCO MARINE: 3430, ARROWHEAD: SHI0128, ARROWHEAD (OEM): S114-828DN, ARROWHEAD (OEM) (OLD): S114-828B, S114-828C, S114-828CN, EMP PARTS: 4-6425, HITACHI: S114-828B, S114-828C, J & N: 410-44071, LESTER: 18347, MERCURY MARINE: 50-804312T1, 804312T1, QUICKSILVER: 8M6007420, SIERRA MARINE: 18-6425, WAI: 18347N, YAMAHA: 67F-81800-00-00, 67F-81800-01-00, 67F-81800-02-00
• Compatible With/Replacement For: MARINER 75ELHPT 4-Stroke 2000-2001, 75ELPT 4-Stroke 2000-2001, 90ELHPT 4-Stroke 2000-2001, 90ELPT 4-Stroke 2000-2001, 90ELPT Coastal 4-Stroke 2000-2000, 90EXLPT Saltwater 4-Stroke 2001-2001, MERCURY MARINE 75.0HP - SN 0G960500 Thru 0T800999 All, 75.0HP - SN 0T801000 Thru 1B226999 All, 75.0HP Bodensee - SN 0G960500 Thru 0T800999 All, 75.0HP Bodensee - SN 0T801000 Thru 1B226999 All, 75ELHPT 4-Stroke 2000-2001, 75ELPT 4-Stroke 2000-2005
• 1-year warranty protects you after your purchase. We're confident that our products will work flawlessly once installed in your vehicle. But in a rare case that it does not, we'll replace it anytime within one year of your order. If you have a problem, we will take every step to assist you, contact us for a replacement.
• 100% New Aftermarket Starter built to meet OEM specifications
